测试编号 |
操作系统适配 |
正常安装结果 |
Troubleshooting安装结果 |
备注 |
|
1 |
windows10 |
通过 |
通过 |
|
|
2 |
centos7.9 |
未通过 |
||
|
3 |
Rocky Linux 10.1 |
通过 |
||
|
4 |
windows11 |
通过 |
||
|
5 |
ubuntu22.04 |
通过 |
||
|
6 |
麒麟V11 |
通过 |
||
|
7 |
|
序号 |
日期 |
版本 |
描述 |
|
1 |
2025/05/17 |
001 |
Initial release |
|
2 |
2025/06/16 |
002 |
Add more DIMMs |
|
3 |
2025/07/16 |
003 |
Add more DIMMs |
|
4 |
2025/08/29 |
004 |
Add more DIMMs and 2DPC list |
|
5 |
2025/09/02 |
005 |
Add SO-DIMM list |
|
6 |
2025/11/20 |
006 |
Add more DIMMs |
POR 规格表
|
DIMM 类型 |
DIMM插槽配置 |
每条 DIMM 的 Rank 数 |
频率(MT/s) |
|
SODIMM |
1 of 1 |
1R |
5600 |
|
2R |
5600 |
||
|
UDIMM |
1 of 2 |
1R 0 |
5600 |
|
2R 0 |
5600 |
||
|
2 of 2 |
1R 1R |
4400 |
|
|
2R 2R |
4000 |
UDIMM 已验证内存矩阵
适用于每通道 2 条插槽(2DPC)的设计
|
序号 |
供应商 |
部件号 |
内存类型 |
内存条容量 |
其它 |
配置 |
内存速率 |
|
1 |
Samsung |
M323R1GB4DB0-CWMOD |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
2 |
Samsung |
M323R2GA3PB0-CWMOD |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
3 |
Samsung |
M324R2GA3DB0-CWMOD |
1Rx8 |
16GB |
PC5-5600B-ED0-1010-XT |
1of2 |
5600 |
|
4 |
Samsung |
M323R4GA3DB0-CWMOD |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
1of2 |
5600 |
|
5 |
Samsung |
M323R4GA3PB0-CWMOL |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
1of2 |
5600 |
|
6 |
Samsung |
M323R4GA3PB0-CWMOD |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
1of2 |
5600 |
|
7 |
Samsung |
M324R4GA3PB0-CWMOD |
2Rx8 |
32GB |
PC5-5600B-EE0-1010-XT |
1of2 |
5600 |
|
8 |
SK Hynix |
HMCG66AGBUA081N |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
9 |
SK Hynix |
HMCG78AGBEA084N |
1Rx8 |
16GB |
PC5-5600B-ED0-1010-XT |
1of2 |
5600 |
|
10 |
SK Hynix |
HMCG88AGBEA084N |
2Rx8 |
32GB |
PC5-5600B-EE0-1010-XT |
1of2 |
5600 |
|
11 |
SK Hynix |
HMCG88AGBEA254N |
2Rx8 |
32GB |
PC5-5600B-EE0-1010-XT |
1of2 |
5600 |
|
12 |
FORESEE |
FD5DU5600C8GHA |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-NT |
1of2 |
5600 |
|
13 |
FORESEE |
FD5DU5600CQGHA |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-NT |
1of2 |
5600 |
|
14 |
FORESEE |
FD5DU5600CWGHA |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-NT |
1of2 |
5600 |
|
15 |
Zentel |
Z6A8GH4SAAA-QE |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
16 |
Zentel |
Z6ABGH3DAAA-QE |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
1of2 |
5600 |
|
17 |
Zentel |
Z6ABGC3DAEA-QE |
2Rx8 |
32GB |
PC5-5600B-EE0-1211-XT |
1of2 |
5600 |
|
18 |
Kimtigo |
KT8GU5PA4-H |
1Rx16 |
8GB |
PC5-5600B-UC1-1010-XT |
1of2 |
5600 |
|
19 |
Kimtigo |
KTFGU5PA8-HM |
1Rx8 |
16GB |
PC5-5600B-UA2-1010-XT |
1of2 |
5600 |
|
20 |
CXMT |
CXMR4FF08U6AS-AN1C |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
21 |
CXMT |
CXMR4FF08U6AS-CN1C |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
22 |
CXMT |
CXMR4FF08U6AS-DN1C |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
23 |
CXMT |
CXMR4FF08U6AS-EN1C |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
24 |
CXMT |
CXMR4E816U6AS-AN1C |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
25 |
CXMT |
CXMR4E816U6AS-CN1C |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
26 |
CXMT |
CXMR4E816U6AS-DN1C |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
27 |
CXMT |
CXMR4E816U6AS-EN1C |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
28 |
UniIC |
SCA08GU04H1F1C-56B |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
29 |
UniIC |
SCA16GU03C2F1C-56B |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
30 |
UniIC |
SCA16GU03H1F1C-56B |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
31 |
UniIC |
UCA16GU03A1F1C-56B |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
32 |
UniIC |
SCA32GU13H1F1C-56B |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
1of2 |
5600 |
|
33 |
UniIC |
SCA32GE13C2F1C-56B |
2Rx8 |
32GB |
PC5-5600B-EE0-1010-XT |
1of2 |
5600 |
|
34 |
SINKER |
SID5U56846HA8 |
1Rx16 |
8GB |
AA005M5U856A01-1.1V |
1of2 |
5600 |
|
35 |
SINKER |
SID5U56A46HA7 |
1Rx8 |
16GB |
AA005M5UA56A01-1.1V |
1of2 |
5600 |
|
36 |
SINKER |
SID5U56B46HA7 |
2Rx8 |
32GB |
AA005M5UA56A01-1.1V |
1of2 |
5600 |
|
37 |
Kingston |
TF56U46BS6HA-8KM |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
1of2 |
5600 |
|
38 |
Kingston |
TF56U46BS8HA-16KM |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
1of2 |
5600 |
|
39 |
Kingston |
TF56U46BD8HA-32KM |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
1of2 |
5600 |
|
40 |
WodpoSIT |
WPBS56D508UWB-16G |
1Rx8 |
16GB |
PC5-5600BN-UA0-1010-XT |
1of2 |
5600 |
|
41 |
UNICORE |
UD5UD56N08E6HA00 |
1Rx16 |
8GB |
NA |
1of2 |
5600 |
|
42 |
UNICORE |
UD5UD56N16E5HA00 |
1Rx8 |
16GB |
NA |
1of2 |
5600 |
|
43 |
UNICORE |
UD5UD56N32E5HA00 |
2Rx8 |
32GB |
NA |
1of2 |
5600 |
|
44 |
Innodisk |
M5CZ-BGH2MC0Q-AHLK |
2Rx8 |
32GB |
NA |
1of2 |
5600 |
|
序号 |
供应商 |
部件号 |
内存类型 |
内存条容量 |
其它 |
配置 |
内存速率 |
|
1 |
Samsung |
M323R1GB4DB0-CWMOD |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
2of2 |
4400 |
|
2 |
Samsung |
M324R2GA3DB0-CWMOD |
1Rx8 |
16GB |
PC5-5600B-ED0-1010-XT |
2of2 |
4400 |
|
3 |
Samsung |
M323R4GA3PB0-CWMOL |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
2of2 |
4000 |
|
4 |
Samsung |
M323R4GA3DB0-CWMOD |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
2of2 |
4000 |
|
5 |
Samsung |
M323R4GA3PB0-CWMOD |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
2of2 |
4000 |
|
6 |
SK Hynix |
M324R4GA3PB0-CWMOD |
2Rx8 |
32GB |
PC5-5600B-EE0-1010-XT |
2of2 |
4000 |
|
7 |
SK Hynix |
HMCG66AGBUA081N |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
2of2 |
4400 |
|
8 |
SK Hynix |
HMCG78AGBEA084N |
1Rx8 |
16GB |
PC5-5600B-ED0-1010-XT |
2of2 |
4400 |
|
9 |
SK Hynix |
HMCG88AGBEA084N |
2Rx8 |
32GB |
PC5-5600B-EE0-1010-XT |
2of2 |
4000 |
|
10 |
SK Hynix |
HMCG88AGBEA254N |
2Rx8 |
32GB |
PC5-5600B-EE0-1010-XT |
2of2 |
4000 |
|
11 |
FORESEE |
FD5DU5600C8GHA |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-NT |
2of2 |
4400 |
|
12 |
FORESEE |
FD5DU5600CQGHA |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-NT |
2of2 |
4400 |
|
13 |
FORESEE |
FD5DU5600CWGHA |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-NT |
2of2 |
4000 |
|
14 |
Zentel |
Z6A8GH4SAAA-QE |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
2of2 |
4400 |
|
15 |
Zentel |
Z6ABGH3DAAA-QE |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
2of2 |
4000 |
|
16 |
CXMT |
CXMR4FF08U6AS-AN1C |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
2of2 |
4400 |
|
17 |
CXMT |
CXMR4FF08U6AS-CN1C |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
2of2 |
4400 |
|
18 |
CXMT |
CXMR4FF08U6AS-DN1C |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
2of2 |
4400 |
|
19 |
CXMT |
CXMR4E816U6AS-AN1C |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
2of2 |
4400 |
|
20 |
CXMT |
CXMR4E816U6AS-CN1C |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
2of2 |
4400 |
|
21 |
CXMT |
CXMR4E816U6AS-DN1C |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
2of2 |
4400 |
|
22 |
CXMT |
CXMR4E816U6AS-EN1C |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
2of2 |
4400 |
|
23 |
UniIC |
SCA08GU04H1F1C-56B |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
2of2 |
4400 |
|
24 |
UniIC |
SCA16GU03H1F1C-56B |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
2of2 |
4400 |
|
25 |
UniIC |
SCA16GU03C2F1C-56B |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
2of2 |
4400 |
|
26 |
UniIC |
SCA32GU13H1F1C-56B |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
2of2 |
4000 |
|
27 |
UniIC |
SCA32GE13C2F1C-56B |
2Rx8 |
32GB |
PC5-5600B-EE0-1010-XT |
2of2 |
4000 |
|
28 |
Kimtigo |
KT8GU5PA4-H |
1Rx16 |
8GB |
PC5-5600B-UC1-1010-XT |
2of2 |
4400 |
|
29 |
Kimtigo |
KTFGU5PA8-HM |
1Rx8 |
16GB |
PC5-5600B-UA2-1010-XT |
2of2 |
4400 |
|
30 |
SINKER |
SID5U56B46HA7 |
2Rx8 |
32GB |
AA005M5UA56A01-1.1V |
2of2 |
4000 |
|
31 |
Kingston |
TF56U46BS6HA-8KM |
1Rx16 |
8GB |
PC5-5600B-UC0-1010-XT |
2of2 |
4400 |
|
32 |
Kingston |
TF56U46BS8HA-16KM |
1Rx8 |
16GB |
PC5-5600B-UA0-1010-XT |
2of2 |
4400 |
|
33 |
Kingston |
TF56U46BD8HA-32KM |
2Rx8 |
32GB |
PC5-5600B-UB0-1010-XT |
2of2 |
4000 |
|
34 |
UNICORE |
UD5UD56N08E6HA00 |
1Rx16 |
8GB |
NA |
2of2 |
4400 |
|
35 |
UNICORE |
UD5UD56N16E5HA00 |
1Rx8 |
16GB |
NA |
2of2 |
4400 |
|
36 |
UNICORE |
UD5UD56N32E5HA00 |
2Rx8 |
32GB |
NA |
2of2 |
4000 |
SODIMM 已验证内存矩阵
适用于每通道 1 条插槽 (1 DPC) 的设计
|
序号 |
供应商 |
部件号 |
内存类型 |
内存条容量 |
其它 |
配置 |
内存速率 |
|
1 |
Samsung |
M425R1GB4PB0-CWMOL |
1Rx16 |
8GB |
PC5-5600B-SC0-1010-XT |
1of1 |
5600 |
|
2 |
Samsung |
M425R2GA3PB0-CWMOL |
1Rx8 |
16GB |
PC5-5600B-SA0-1010-XT |
1of1 |
5600 |
|
3 |
Samsung |
M425R4GA3PB0-CWMOL |
2Rx8 |
32GB |
PC5-5600B-SB0-1010-XT |
1of1 |
5600 |
|
4 |
SK Hynix |
HMCG66AGBSA092N |
1Rx16 |
8GB |
PC5-5600B-SC0-1010-XT |
1of1 |
5600 |
|
5 |
SK Hynix |
HMCG66AGBSA092N |
1Rx8 |
16GB |
PC5-5600B-SA0-1010-XT |
1of1 |
5600 |
|
6 |
SK Hynix |
HMCG66AGBSA092N |
1Rx8 |
16GB |
PC5-5600B-SA0-1010-XT |
1of1 |
5600 |
|
7 |
SK Hynix |
HMCG78AGBSA095N |
1Rx8 |
168GB |
PC5-5600B-SA0-1010-XT |
1of1 |
5600 |
|
8 |
SK Hynix |
HMCG88AGBAA092N |
2Rx8 |
32GB |
PC5-5600B-TE0-1010-XT |
1of1 |
5600 |
|
9 |
Kingston |
CBD56S46BS6HA-8 |
1Rx16 |
8GB |
9905801-E18.A00G |
1of1 |
5600 |
|
10 |
Kingston |
CBD56S46BS8HA-16 |
1Rx8 |
16GB |
9905790-E23.A00G |
1of1 |
5600 |
|
11 |
UniIC |
SCA08GS04H1F1C-56B |
1Rx16 |
8GB |
PC5-5600B-SC0-1010-XT |
1of1 |
5600 |
|
12 |
UniIC |
SCA16GS03H1F1C-56B |
1Rx8 |
16GB |
PC5-5600B-SA0-1010-XT |
1of1 |
5600 |
|
13 |
FORESEE |
FD5DS5600C8GHA |
1Rx16 |
8GB |
PC5-5600B-SC0-1010-NT |
1of1 |
5600 |
|
14 |
FORESEE |
FD5DS5600CQGHA |
1Rx8 |
16GB |
PC5-5600B-SA0-1010-NT |
1of1 |
5600 |
|
15 |
FORESEE |
FD5DS5600CWGHA |
2Rx8 |
32GB |
PC5-5600B-SB0-1010-NT |
1of1 |
5600 |
暂无评论内容
